Low-Frequency RFID Antennas
Low-Frequency Rod RFID Antenna
Key Features:
- RFID antenna in rod format
- Various cable lengths available
- Robust plug guarantees secure connection
Features include a robust plug, which guarantees a secure connection.
Specifications
| Type | Rod antenna |
| Antenna cylinder length | 125mm | 4.9 inches |
| Antenna cylinder diameter | 23mm | 0.9 inches |
| Complete mounting dimensions | 150mm | 5.9 inches (cable with 90-degree angle) |
| Antenna housing | ABS |
| Cable material | PVC |
| Antenna cable diameter | 5.5mm | 0.2 inches |
| Operating temperature | 0°C to 50°C | 32°F to 122°F |
| Storage temperature | -25°C to 70°C | -13°F to 158°F |
| Permissible humidity | 25% to 80% at 50°C | 122°F |
| Part numbers for LF80C ZeniD | Cable length |
| ANT-1S10 | 1000mm |
| ANT-1S15 | 1500mm |
Low-Frequency Micro RFID Antenna
Key Features:
- RFID antenna in rod format
- Various cable lengths available
- Robust plug guarantees a secure connection
Features include various cable lengths and a robust plug, guaranteeing a secure connection.
Specifications
| Type | Rod antenna |
| Antenna cylinder length | 40mm | 1.6 inches |
| Antenna cylinder diameter | 10mm | 0.4 inches |
| Complete mounting dimensions | 60mm | 2.4 inches (cable with 90-degree angle) |
| Antenna housing | PP, light gray |
| Cable material | PVC |
| Antenna cable diameter | 4.1mm | 0.2 inches |
| Operating temperature | 0°C to 50°C | 32°F to 122°F |
| Storage temperature | -25°C to 70°C | -13°F to 158°F |
| Permissible humidity | 25% to 80% at 50°C | 122°F |
| Part numbers for LF80C ZeniD | Cable length |
| ANT-1M10 ANT-1M10-SMH | 1000mm |
| ANT-1M15 | 1500mm |
| ANT-1M25 | 2500mm |
| ANT-1M40-FLEX | 4000mm |
Low-Frequency Mini RFID Antenna
Key Features:
- RFID antenna in rod format
- Various cable lengths available
- Robust plug guarantees a secure connection
Features include a RFID antenna in rod format and various cable lengths.
Specifications
| Type | Rod antenna |
| Antenna cylinder length | 68mm | 2.7 inches |
| Antenna cylinder diameter | 10mm | 0.4 inches |
| Complete mounting dimensions | 85mm | 3.3 inches (cable with 90-degree angle) |
| Antenna housing | PP, light gray |
| Cable material | PVC |
| Antenna cable diameter | 4.1mm | 0.2 inches |
| Operating temperature | 0°C to 50°C | 32°F to 122°F |
| Storage temperature | -25°C to 70°C | -13°F to 158°F |
| Permissible humidity | 25% to 80% at 50°C | 122°F |
| Part numbers for LF80C ZeniD | Part numbers for ATR60LF SMA | Cable length |
| ANT-1K10 ANT-1K10-FLEX | ANT-7K10 | 1000mm |
| - | ANT-7K12 | 1200mm |
| ANT-1K15 | 1500mm | |
| ANT-1K20 | ANT-7K20 | 2000mm |
